Description
Trailer Release Valve
Part Number: 9630010130
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Actuation | Black/Black |
| Application | 971 002 |
| Calculated Volume (dm³) | 0.2959 |
| Color | Knob – Black |
| Comments | With non-return valve |
| Distance between holes | 86 mm |
| Max. operating pressure | 8.5 bar |
| Mounting | 2 x M8 – with flange |
| Port thread 1-1 | M22 x1.5 |
| Port thread 1-2 | Ø 7.0 mm |
| Port thread 2 | Ø 21.5 mm |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port threads | M22 x 1.5 |
| Product category | Device |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Double Release valve |
| GTIN | 04057875298489 |
| Size (mm x mm x mm) | 90.5 x 54.5 x 60 |
| UPC | 193133449393 |
| Weight (kg) | 0.132 |
| Weight (lb) | 0.291 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 1325328 |
| EVOBUS | 8283706000 |
| EVOBUS | 82838848550 |
| FAYMONVILLE | 113667 |
| FELDBINDER | 011626 |
| FREIGHTLINER | TDAS9630010130 |
| GOLDHOFER | 163623 |
| KENWORTH | S963-001-013-0 |
| KENWORTH | S9710027030 |
| KÖGEL | 185055 |
| MACK | 6300-9630010130 |
| MACK | 6300-9710027030 |
| MAN | 82523106008 |
| MERITOR | S9630010130 |
| MERITOR | S9710027030 |
| NOOTEBOOM | 0308065 |
| NOOTEBOOM | 08052 |
| PETERBILT | S963-001-013-0 |
| PETERBILT | S9710027030 |
| RENAULT | 5021170425 |
| SCANIA | 2090265 |
| SCANIA | 2090082 |
| SCHMITZ CARGOBULL | 50309 |
| SCHWARZMÜLLER | 23740 |
| VAN HOOL | 10976129 |
| VOLVO | WAB9630010130 |
| VOLVO | WAB9710027030 |
| ZORZI | 1012003 |
