Description
OEM WPL Trailer (Poland)
Part Number: 4801020330
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Calculated Volume (dm³) | 11.53 |
| Distance between bolts | 70 mm |
| Max. operating pressure | 8.5 bar |
| Mounting | 2x M12 |
| Port thread 1 | 15 x 1.5 / 8 x 1 |
| Port thread 11 | 12 x 1.5 / 8 x 1 |
| Port thread 21 | 12 x 1.5 |
| Port thread 22 | 12 x 1.5 |
| Port thread 23 | 8 x 1 |
| Port thread 24 | 8 x 1 |
| Port thread 3 | 2 Integrated Silencer |
| Port thread 4 | 8 x 1 |
| Port thread 42 | 8 x 1 |
| Port thread 5 | 8 x 1 |
| Product category | Device |
| Protection class | IP 6K9K |
| System | 2S/2M |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | Standard |
| Version | TEBS E with PEM |
| Voltage | 24 V |
| GTIN | 04057875228691 |
| Size (mm x mm x mm) | 224 x 260 x 198 |
| UPC | 193133317166 |
| Weight (kg) | 6.195 |
| Weight (lb) | 13.66 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 0906315 |
| FAYMONVILLE | 191656 |
| KRONE | 515017225 |
| KÄSSBOHRER | 21150110177 |
| OTOKAR | AIF2005 |
| SCANIA | 2090388 |
| SCHMITZ CARGOBULL | 1042742 |
| SCHMITZ CARGOBULL | 1124337 |
| SCHMITZ CARGOBULL | 1161208 |
| SCHWARZMÜLLER | 80330 |
| TIRSAN | 21150110177 |
| VAN HOOL | 11065751 |
| VOLVO | WA4801020330 |
