Description
Specifications
| Inner brake drum diameter | 220 mm |
| Inner brake drum height | 54 mm |
| Total brake drum height | 64 mm |
| Rim Hole Number | 5 |
| Wheel Hub Diameter | 108 mm |
| Outer brake drum diameter | 262 mm |
| Bolt Hole Circle Ø | 139.7 mm |
| Weight | 6.24 kg |
| Country of Origin | Netherlands |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| CHEVROLET | 30024672 |
| SUZUKI | 43511-65D10, 4351167D01 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| ABE | C68021ABE |
| ATE | 24.0222-0003.1 |
| BLUE PRINT | ADK84705 |
| BREMSI | CR5810 |
| CHEVROLET | 30024672 |
| DELPHI | BF531 |
| FREMAX | BD-4804 |
| FTE | 9190022 |
| HAVAM | HP66610 |
| HELLA | 8DT 355 303-171 |
| JAPANPARTS | TA-805, TA-805C, TA805JM |
| JAPKO | 56805C |
| JP GROUP | 4763500200 |
| KAVO PARTS | BD-8864 |
| KAWE | 7D0669 |
| LPR | 7D0669 |
| MAXGEAR | 19-3222 |
| MINTEX | MBD407 |
| NK | 255207 |
| NPS | S340I08 |
| OMC | 100812 |
| PEMEBLA | BNXBDM1157, JAPTA-805, JAPTA-805C, JAPTA805JM |
| RIDEX | 123B0116 |
| SUZUKI | 43511-65D10, 4351167D01 |
| Stark | SKBDM-0800115 |
| TEXTAR | 94045700 |
| TRISCAN | 8120 69214 |
| TRW | DB4444 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| GRAND VITARA I (FT, HT) 2.0 TD 4×4 (SQ 420D) | 2000-04 – 2005-09 | 63 | 1998 | ||
| GRAND VITARA I (FT, HT) 1.6 4×4 (SQ416) | 1998-03 – 2003-07 | 69 | 94 | 1590 | |
| GRAND VITARA I (FT, HT) 2.0 4×4 (TA52, TL52, SQ420) | 1998-03 – 2003-07 | 94 | 128 | 1995 | |
| GRAND VITARA I (FT, HT) 2.5 V6 24V 4×4 (SQ625) | 2001-04 – 2003-07 | 116 | 158 | 2493 | |
| GRAND VITARA I (FT, HT) 2.5 V6 24V 4×4 (TD62, SQ625) | 1998-04 – 2003-07 | 106 | 144 | 2493 | |
| GRAND VITARA I (FT, HT) 2.7 4×4 (TX92, JA627) | 2003-04 – 2003-07 | 135 | 184 | 2736 |
