Description
Specifications
| paired article number | 2147295 |
| Fitting Position | Rear Axle Right; behind the axle |
| Manufacturer Restriction | LUCAS |
| Brake Caliper Type | Brake Caliper with integrated parking brake; Brake Caliper (1 piston) |
| Piston Diameter | 34 mm |
| for brake disc thickness | 9 mm |
| Brake Disc Type | solid |
| for brake disc diameter | 232 mm |
| Material | Aluminium |
| Cable ID | Ø 6,0 mm |
| Net weight | 1.51 kg |
| Weight | 1.608 kg |
| Country of Origin | China |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| AUDI | 6Q0615424A |
| SEAT | 6Q0615424A |
| SKODA | 6Q0615424A |
| VAG | 6Q0615424A, 6Q0615424B |
| VW | 6Q0615424A, 6Q0615424B |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| ATE | 24.3344-1710.7 |
| AUDI | 6Q0615424A |
| BOSCH | 0986474180 |
| BREMBO | F85217 |
| BUDWEG CALIPER | 343435 |
| Brake ENGINEERING | CA2197R |
| CARDONE | 384517 |
| DELCO REMY | DC73435 |
| DELPHI | LC7610 |
| DRI | 4284500 |
| ELSTOCK | 87-0854 |
| FTE | RS349810A0, RX349810A0 |
| HELLA | 8AC355381-041, 8AN355440-181 |
| RE-EX | 506-02595 |
| SEAT | 6Q0615424A |
| SHAFTEC | BC8913R |
| SKODA | 6Q0615424A |
| TMI | BR002595 |
| TRW | BHQ144, BHQ144E |
| UBD | 54953 |
| VAG | 6Q0615424A, 6Q0615424B |
| VW | 6Q0615424A, 6Q0615424B |
| sbs | 13012147296 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| A2 (8Z0) 1.4 TDI | 2000-02 – 2005-08 | 55 | 75 | 1422 | |
| A2 (8Z0) 1.4 TDI | 2003-11 – 2005-08 | 66 | 90 | 1422 | |
| A2 (8Z0) 1.6 FSI | 2002-05 – 2005-08 | 81 | 110 | 1598 | |
| CORDOBA (6L2) 1.2 | 2002-10 – 2006-06 | 47 | 64 | 1198 | |
| CORDOBA (6L2) 1.2 12V | 2006-05 – 2009-11 | 51 | 70 | 1198 | |
| CORDOBA (6L2) 1.4 16V | 2002-09 – 2007-12 | 55 | 75 | 1390 | |
| CORDOBA (6L2) 1.4 16V | 2002-10 – 2009-11 | 74 | 100 | 1390 | |
| CORDOBA (6L2) 1.4 16V | 2006-05 – 2009-11 | 63 | 86 | 1390 | |
| CORDOBA (6L2) 1.4 TDI | 2002-10 – 2005-12 | 55 | 75 | 1422 | |
| CORDOBA (6L2) 1.4 TDI | 2005-06 – 2009-11 | 59 | 80 | 1422 | |
| CORDOBA (6L2) 1.9 SDI | 2002-09 – 2009-11 | 47 | 64 | 1896 | |
| CORDOBA (6L2) 1.9 TDI | 2002-10 – 2009-11 | 96 | 131 | 1896 | |
| CORDOBA (6L2) 1.9 TDI | 2002-09 – 2009-11 | 74 | 100 | 1896 | |
| CORDOBA (6L2) 1.4 TDI | 2005-05 – 2009-11 | 51 | 70 | 1422 | |
| CORDOBA (6L2) 1.6 | 2003-04 – 2009-11 | 74 | 101 | 1598 | |
| CORDOBA (6L2) 1.6 16V | 2006-11 – 2009-11 | 77 | 105 | 1598 | |
| CORDOBA (6L2) 2.0 | 2002-09 – 2009-11 | 85 | 115 | 1984 | |
| IBIZA III (6L1) 1.4 16V | 2002-02 – 2009-11 | 74 | 100 | 1390 | |
| IBIZA III (6L1) 1.4 16V | 2002-02 – 2007-12 | 55 | 75 | 1390 | |
| IBIZA III (6L1) 1.4 16V | 2006-05 – 2009-11 | 63 | 86 | 1390 | |
| IBIZA III (6L1) 1.4 TDI | 2005-05 – 2009-11 | 51 | 70 | 1422 | |
| IBIZA III (6L1) 1.4 TDI | 2005-06 – 2009-11 | 59 | 80 | 1422 | |
| IBIZA III (6L1) 1.6 | 2003-02 – 2009-11 | 74 | 101 | 1598 | |
| IBIZA III (6L1) 1.6 16V | 2006-11 – 2009-11 | 77 | 105 | 1598 | |
| IBIZA III (6L1) 1.9 SDI | 2002-02 – 2005-12 | 47 | 64 | 1896 | |
| IBIZA III (6L1) 1.9 TDI | 2002-02 – 2009-11 | 74 | 100 | 1896 | |
| IBIZA III (6L1) 1.9 TDI | 2002-02 – 2009-11 | 96 | 131 | 1896 | |
| IBIZA III (6L1) 2.0 | 2002-04 – 2009-11 | 85 | 116 | 1984 | |
| POLO IV (9N_, 9A_) 1.2 12V | 2001-10 – 2007-07 | 47 | 64 | 1198 | |
| POLO IV (9N_, 9A_) 1.2 12V | 2007-05 – 2009-11 | 51 | 69 | 1198 | |
| POLO IV (9N_, 9A_) 1.4 16V | 2001-10 – 2008-05 | 55 | 75 | 1390 | |
| POLO IV (9N_, 9A_) 1.4 16V | 2006-05 – 2009-11 | 59 | 80 | 1390 | |
| POLO IV (9N_, 9A_) 1.4 TDI | 2005-04 – 2009-11 | 59 | 80 | 1422 | |
| POLO IV (9N_, 9A_) 1.4 TDI | 2005-04 – 2009-11 | 51 | 70 | 1422 | |
| POLO IV (9N_, 9A_) 1.6 16V | 2006-05 – 2009-11 | 77 | 105 | 1598 | |
| POLO IV (9N_, 9A_) 1.8 GTI | 2005-09 – 2009-11 | 110 | 150 | 1781 | |
| POLO IV (9N_, 9A_) 1.8 GTi Cup Edition | 2006-05 – 2009-11 | 132 | 180 | 1781 | |
| POLO IV Saloon (9A4, 9A2, 9N2, 9A6) 1.6 | 2002-09 – … | 74 | 1598 | ||
| POLO IV Saloon (9N2, 9N4) 1.9 TDI | 2003-07 – 2010-12 | 74 | 1896 | ||
| POLO IV (9N_, 9A_) 1.2 | 2002-01 – 2007-05 | 40 | 54 | 1198 | |
| POLO IV (9N_, 9A_) 1.2 | 2007-05 – 2009-11 | 44 | 60 | 1198 | |
| POLO IV (9N_, 9A_) 1.4 16V | 2001-10 – 2008-05 | 74 | 101 | 1390 | |
| POLO IV (9N_, 9A_) 1.4 FSI | 2002-02 – 2006-07 | 63 | 86 | 1390 | |
| POLO IV (9N_, 9A_) 1.4 TDI | 2001-10 – 2005-06 | 55 | 75 | 1422 | |
| POLO IV (9N_, 9A_) 1.9 SDI | 2001-10 – 2009-11 | 47 | 64 | 1896 | |
| POLO IV (9N_, 9A_) 1.9 TDI | 2001-10 – 2009-11 | 74 | 101 | 1896 | |
| POLO IV (9N_, 9A_) 1.9 TDI | 2003-11 – 2009-11 | 96 | 130 | 1896 | |
| POLO IV Saloon (9A4, 9A2, 9N2, 9A6) 1.4 | 2002-11 – 2012-04 | 55 | 75 | 1390 | |
| POLO IV Saloon (9A4, 9A2, 9N2, 9A6) 1.4 | 2003-11 – 2005-06 | 74 | 101 | 1390 | |
| POLO IV Saloon (9A4, 9A2, 9N2, 9A6) 1.4 TDI | 2003-07 – 2005-06 | 55 | 75 | 1422 | |
| POLO IV Saloon (9A4, 9A2, 9N2, 9A6) 1.9 SDI | 2002-09 – 2012-04 | 47 | 64 | 1896 |
