Description
Specifications
| paired article number | 2133166 |
| Fitting Position | Front Axle Left; in front of axle |
| Manufacturer Restriction | ATE |
| Brake Caliper Type | Floating Caliper; Brake Caliper (1 piston) |
| Piston Diameter | 57 mm |
| for brake disc thickness | 25 mm |
| Brake Disc Type | Vented |
| for brake disc diameter | 288 mm |
| Material | Cast Iron |
| Net weight | 3.8 kg |
| Weight | 3.8 kg |
| Country of Origin | China |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| MERCEDES-BENZ | 0014202983, A0014202983 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| ATE | 11.3571-8511.2, 24.3571-8511.5 |
| BENDIX | 692758B |
| BOSCH | 0986473096 |
| BREMBO | F50122 |
| BUDWEG CALIPER | 342534 |
| Brake ENGINEERING | CA1647 |
| CARDONE | 388341 |
| DELCO REMY | DC82534 |
| DELPHI | LC7417 |
| DRI | 3156100 |
| ELSTOCK | 82-0516 |
| ERA Benelux | BC62534 |
| FRIESEN | QBS2737 |
| FTE | RX571309A0 |
| GENERAL RICAMBI | ME6121 |
| HELLA | 8AC355391-351 |
| MERCEDES-BENZ | 0014202983, A0014202983 |
| RE-EX | 506-01544 |
| TMI | BR001544 |
| TRW | BHX328E |
| UBD | 54046 |
| sbs | 13012133165 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| C-CLASS (W202) C 200 Kompressor (202.025) | 1995-10 – 2000-05 | 132 | 180 | 1998 | |
| C-CLASS T-Model (S202) C 200 T Kompressor (202.082) | 1996-11 – 2001-03 | 141 | 192 | 1998 | |
| C-CLASS T-Model (S202) C 200 T Kompressor (202.087) | 2000-09 – 2001-03 | 120 | 163 | 1998 | |
| C-CLASS T-Model (S202) C 230 T Kompressor (202.085) | 1997-06 – 2000-09 | 142 | 193 | 2295 | |
| C-CLASS T-Model (S202) C 240 T (202.086) | 1997-06 – 2000-09 | 125 | 170 | 2398 | |
| C-CLASS T-Model (S202) C 240 T (202.088) | 2000-09 – 2001-03 | 125 | 170 | 2597 | |
| C-CLASS T-Model (S202) C 250 T Turbo-D (202.188) | 1996-06 – 2001-03 | 110 | 150 | 2497 | |
| C-CLASS T-Model (S202) C 280 T (202.089) | 1997-06 – 2001-03 | 145 | 197 | 2799 | |
| C-CLASS (W202) C 200 Kompressor (202.025) | 1996-11 – 2000-05 | 141 | 192 | 1998 | |
| C-CLASS (W202) C 230 Kompressor (202.024) | 1995-10 – 2000-05 | 142 | 193 | 2295 | |
| C-CLASS (W202) C 240 (202.026) | 1997-06 – 2000-05 | 125 | 170 | 2398 | |
| C-CLASS (W202) C 250 Turbo-D (202.128) | 1995-10 – 2000-05 | 110 | 150 | 2497 | |
| C-CLASS (W202) C 280 (202.028) | 1993-05 – 2000-05 | 142 | 193 | 2799 | |
| C-CLASS (W202) C 280 (202.029) | 1997-06 – 2000-05 | 145 | 197 | 2799 | |
| CLK Convertible (A208) CLK 200 (208.435) | 1998-03 – 2002-03 | 100 | 136 | 1998 | |
| CLK (C208) CLK 200 (208.335) | 1997-06 – 2002-06 | 100 | 136 | 1998 | |
| CLK (C208) CLK 200 Kompressor (208.344) | 2000-06 – 2002-06 | 120 | 163 | 1998 | |
| CLK (C208) CLK 200 Kompressor (208.345) | 1997-06 – 2000-06 | 141 | 192 | 1998 | |
| CLK (C208) CLK 230 Kompressor (208.347) | 1997-06 – 2000-06 | 142 | 193 | 2295 | |
| CLK (C208) CLK 230 Kompressor (208.348) | 2000-06 – 2002-06 | 145 | 197 | 2295 | |
| E-CLASS T-Model (S210) E 200 T (210.235) | 1996-06 – 2000-08 | 100 | 136 | 1998 | |
| E-CLASS (W210) E 300 D (210.020) | 1995-06 – 1997-06 | 100 | 136 | 2996 | |
| E-CLASS (W210) E 220 D (210.004) | 1995-06 – 1999-07 | 70 | 95 | 2155 | |
| E-CLASS (W210) E 220 CDI (210.006) | 1999-07 – 2002-03 | 105 | 143 | 2148 | |
| E-CLASS (W210) E 250 D (210.010) | 1995-06 – 1999-07 | 83 | 113 | 2497 | |
| E-CLASS T-Model (S210) E 220 T CDI (210.206) | 1999-05 – 2003-03 | 100 | 136 | 2148 | |
| E-CLASS T-Model (S210) E 200 T Kompressor (210.248) | 2000-08 – 2003-03 | 120 | 163 | 1998 | |
| E-CLASS T-Model (S210) E 220 T CDI (210.206) | 1998-06 – 1999-07 | 92 | 125 | 2151 | |
| E-CLASS T-Model (S210) E 220 T CDI (210.206) | 1999-07 – 2003-03 | 105 | 143 | 2148 | |
| E-CLASS T-Model (S210) E 230 T (210.237) | 1996-06 – 1997-06 | 110 | 150 | 2295 | |
| E-CLASS T-Model (S210) E 240 T (210.261) | 1997-06 – 2003-03 | 125 | 170 | 2398 | |
| E-CLASS T-Model (S210) E 240 T (210.262) | 2000-08 – 2003-03 | 125 | 170 | 2597 | |
| E-CLASS T-Model (S210) E 250 T D (210.210) | 1996-06 – 1999-07 | 83 | 113 | 2497 | |
| E-CLASS T-Model (S210) E 250 T Turbo-D (210.215) | 1997-06 – 1999-07 | 110 | 150 | 2497 | |
| E-CLASS T-Model (S210) E 290 T Turbo-D (210.217) | 1996-06 – 1999-07 | 95 | 129 | 2874 | |
| E-CLASS (W210) E 200 (210.035) | 1995-06 – 2000-08 | 100 | 136 | 1998 | |
| E-CLASS (W210) E 200 CDI (210.007) | 1998-06 – 2002-03 | 75 | 102 | 2151 | |
| E-CLASS (W210) E 200 CDI (210.007) | 1999-07 – 2002-03 | 85 | 116 | 2148 | |
| E-CLASS (W210) E 200 D (210.003) | 1996-01 – 2002-03 | 65 | 88 | 1997 | |
| E-CLASS (W210) E 200 Kompressor (210.048) | 2000-08 – 2002-03 | 120 | 163 | 1998 | |
| E-CLASS (W210) E 220 CDI (210.006) | 1999-07 – 2002-03 | 100 | 136 | 2148 | |
| E-CLASS (W210) E 220 CDI (210.006) | 1998-06 – 1999-07 | 92 | 125 | 2151 | |
| E-CLASS (W210) E 220 D | 1996-05 – 2002-03 | 55 | 75 | 2155 | |
| E-CLASS (W210) E 230 (210.037) | 1995-06 – 1997-06 | 110 | 150 | 2295 | |
| E-CLASS (W210) E 240 (210.061) | 1997-06 – 2000-08 | 125 | 170 | 2398 | |
| E-CLASS (W210) E 240 (210.062) | 2000-08 – 2002-03 | 125 | 170 | 2597 | |
| E-CLASS (W210) E 250 Turbo-D (210.015) | 1997-06 – 1999-07 | 110 | 150 | 2497 | |
| E-CLASS (W210) E 290 Turbo-D (210.017) | 1996-03 – 1999-07 | 95 | 129 | 2874 | |
| SLK (R170) 200 (170.435) | 1996-09 – 2000-03 | 100 | 136 | 1998 | |
| SLK (R170) 200 Kompressor (170.444) | 2000-03 – 2004-04 | 120 | 163 | 1998 | |
| SLK (R170) 200 Kompressor (170.445) | 1996-10 – 2000-03 | 141 | 192 | 1998 | |
| SLK (R170) 230 Kompressor (170.447) | 1996-09 – 2000-03 | 142 | 193 | 2295 | |
| SLK (R170) 230 Kompressor (170.449) | 2000-03 – 2004-04 | 145 | 197 | 2295 |
