Description
Specifications
| paired article number | 2133137 |
| Fitting Position | Rear Axle Right; in front of axle |
| Manufacturer Restriction | ATE |
| Brake Caliper Type | Floating Caliper; Brake Caliper (1 piston) |
| Piston Diameter | 52 mm |
| for brake disc thickness | 16 mm |
| Brake Disc Type | solid |
| for brake disc diameter | 272 mm |
| Material | Cast Iron |
| Net weight | 3.32 kg |
| Weight | 3.32 kg |
| Country of Origin | China |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| MERCEDES-BENZ | 0024201183, 9024200602, 9024203502, 9024203502, A0024201183, A9024200602, A9024203502 |
| VAG | 2D0615424, A0024201183, A9024200602 |
| VW | 2D0615424, A0024201183, A9024200602 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| ATE | 11.3521-8502.2 |
| BOSCH | 0986474353 |
| BREMBO | F50147 |
| BUDWEG CALIPER | 342847 |
| Brake ENGINEERING | CA1846R |
| CARDONE | 387932 |
| CEF | 6506053 |
| DELCO REMY | DC72847 |
| DELPHI | LC4907 |
| DRI | 4256200 |
| ELSTOCK | 87-0526 |
| FTE | RX529808A0 |
| HELLA | 8AC355388-821 |
| MERCEDES-BENZ | 0024201183, 9024200602, 9024203502, A0024201183, A9024200602, A9024203502 |
| RE-EX | 506-01573 |
| SHAFTEC | BC9264R |
| TMI | BR001573 |
| TRW | BHS315E |
| VAG | 2D0615424, A0024201183, A9024200602 |
| VW | 2D0615424, A0024201183, A9024200602 |
| sbs | 13012133138 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| SPRINTER 2-t Van (B901, B902) 208 CDI (901.661, 901.662, 902.661, 902.662) | 2000-04 – 2006-05 | 60 | 82 | 2148 | |
| SPRINTER 3-t Platform/Chassis (B903) 310 D 2.9 (903.411, 903.412, 903.413, 903.421, 903.422,… | 1997-01 – 2000-04 | 75 | 102 | 2874 | |
| SPRINTER 3-t Platform/Chassis (B903) 311 CDI (903.611, 903.612, 903.613, 903.621, 903.622,… | 2000-04 – 2006-05 | 80 | 109 | 2148 | |
| SPRINTER 3-t Platform/Chassis (B903) 311 CDI 4×4 (903.612, 903.613, 903.622, 903.623) | 2000-04 – 2006-05 | 80 | 109 | 2148 | |
| SPRINTER 3-t Platform/Chassis (B903) 312 D 2.9 (903.411, 903.412, 903.421, 903.422, 903.423) | 1995-02 – 2000-04 | 90 | 122 | 2874 | |
| SPRINTER 3-t Platform/Chassis (B903) 313 CDI (903.611, 903.612, 903.621, 903.622, 903.623,… | 2000-04 – 2006-05 | 95 | 129 | 2148 | |
| SPRINTER 3-t Platform/Chassis (B903) 313 CDI 4×4 (903.612, 903.613, 903.622, 903.623) | 2000-04 – 2006-05 | 95 | 129 | 2148 | |
| SPRINTER 3-t Platform/Chassis (B903) 314 (903.011, 903.012, 903.013, 903.022, 903.612,… | 1995-02 – 2006-05 | 105 | 143 | 2295 | |
| SPRINTER 3-t Platform/Chassis (B903) 314 4×4 (903.612, 903.613, 903.622) | 1995-02 – 2006-05 | 105 | 143 | 2295 | |
| SPRINTER 3-t Platform/Chassis (B903) 314 NGT (903.611, 903.612, 903.613, 903.622, 903.012,… | 1995-02 – 2006-05 | 95 | 125 | 2295 | |
| SPRINTER 3-t Platform/Chassis (B903) 316 CDI (903.611, 903.612, 903.613, 903.621, 903.622,… | 2000-04 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 3-t Platform/Chassis (B903) 316 CDI 4×4 (903.612, 903.613, 903.622, 903.623) | 2002-08 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 3-t Van (B903) 310 D 2.9 4×4 (903.461, 903.462) | 1997-06 – 2000-04 | 75 | 2874 | ||
| SPRINTER CLASSIC 3,5-t Van (B909) 311 CDI (909.632, 909.633) | 2013-09 – … | 80 | 2148 | ||
| SPRINTER 3-t Bus (B903) 310 D (903.471, 903.472, 903.473) | 1997-01 – 1999-12 | 75 | 2874 | ||
| SPRINTER 3-t Platform/Chassis (B903) 310 D 2.9 4×4 (903.421, 903.422, 903.423) | 1997-01 – 2000-04 | 75 | 2874 | ||
| SPRINTER 3-t Platform/Chassis (B903) 312 D 2.9 (903.411, 903.412, 903.413, 903.421, 903.422,… | 1998-12 – 2001-09 | 85 | 116 | 2874 | |
| SPRINTER 3-t Bus (B903) 308 D (903.371, 903.372, 903.373) | 1997-03 – 2000-04 | 60 | 82 | 2299 | |
| SPRINTER 2-t Platform/Chassis (B901, B902) 208 D (901.311, 901.312, 901.321, 902.311, 902.312,… | 1995-01 – 2000-04 | 58 | 79 | 2299 | |
| SPRINTER 2-t Van (B901, B902) 208 D (901.361, 901.362, 902.361, 902.362) | 1995-02 – 2000-04 | 58 | 79 | 2299 | |
| SPRINTER 2-t Van (B901, B902) 208 D (901.361, 901.362, 902.361, 902.362) | 1996-10 – 2000-04 | 60 | 82 | 2299 | |
| SPRINTER 2-t Van (B901, B902) 210 D (901.461, 901.462, 902.461, 902.462) | 1997-01 – 2000-04 | 75 | 102 | 2874 | |
| SPRINTER 2-t Van (B901, B902) 212 D (901.461, 901.462, 902.461, 902.462) | 1995-02 – 2000-04 | 90 | 122 | 2874 | |
| SPRINTER 2-t Van (B901, B902) 214 (901.061, 901.062, 901.661, 901.662, 902.061,… | 1995-02 – 2006-05 | 105 | 143 | 2295 | |
| SPRINTER 2-t Van (B901, B902) 214 NGT (901.661, 902.061, 902.062, 902.661, 902.662) | 1995-02 – 2006-05 | 95 | 125 | 2295 | |
| SPRINTER 2-t Van (B901, B902) 216 CDI (902.661, 902.662) | 2000-04 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 2-t Bus (B901, B902) 208 CDI (901.671, 902.671, 902.672) | 2000-04 – 2006-05 | 60 | 82 | 2148 | |
| SPRINTER 2-t Bus (B901, B902) 208 D (901.371, 902.371, 902.372) | 1995-02 – 2000-04 | 58 | 79 | 2299 | |
| SPRINTER 2-t Bus (B901, B902) 210 D (902.471, 902.472) | 1997-03 – 2000-04 | 75 | 102 | 2874 | |
| SPRINTER 2-t Bus (B901, B902) 211 CDI (902.671, 902.672) | 2000-04 – 2006-05 | 80 | 109 | 2148 | |
| SPRINTER 2-t Bus (B901, B902) 212 D (902.471, 902.472) | 1995-02 – 2000-04 | 90 | 122 | 2874 | |
| SPRINTER 2-t Bus (B901, B902) 213 CDI (902.671, 902.672) | 2000-04 – 2006-05 | 95 | 129 | 2148 | |
| SPRINTER 2-t Bus (B901, B902) 214 (902.071, 902.072, 902.671, 902.672) | 1995-02 – 2006-05 | 105 | 143 | 2295 | |
| SPRINTER 2-t Bus (B901, B902) 214 NGT (902.072, 902.671, 902.672) | 1995-02 – 2006-05 | 95 | 125 | 2295 | |
| SPRINTER 2-t Bus (B901, B902) 216 CDI (902.671, 902.672) | 2000-04 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 2-t Platform/Chassis (B901, B902) 208 D (901.311, 901.312, 901.321, 902.311, 902.312,… | 1996-09 – 2000-04 | 60 | 82 | 2299 | |
| SPRINTER 2-t Platform/Chassis (B901, B902) 210 D (901.421, 902.412) | 1997-01 – 2000-04 | 75 | 102 | 2874 | |
| SPRINTER 2-t Platform/Chassis (B901, B902) 211 CDI (901.621, 902.611, 902.612, 902.621, 902.622) | 2000-04 – 2006-05 | 80 | 109 | 2148 | |
| SPRINTER 2-t Platform/Chassis (B901, B902) 212 D (901.421, 902.412) | 1995-02 – 2000-04 | 90 | 122 | 2874 | |
| SPRINTER 2-t Platform/Chassis (B901, B902) 216 CDI (902.611, 902.612, 902.621, 902.622) | 2000-04 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 3-t Van (B903) 308 CDI (903.661, 903.662, 903.663) | 2000-04 – 2006-05 | 60 | 82 | 2148 | |
| SPRINTER 3-t Van (B903) 308 D 2.3 (903.361, 903.362, 903.363) | 1995-02 – 2000-04 | 58 | 79 | 2299 | |
| SPRINTER 3-t Van (B903) 308 D 2.3 (903.361) | 1995-02 – 2000-04 | 60 | 82 | 2299 | |
| SPRINTER 3-t Van (B903) 310 D 2.9 (903.461, 903.462, 903.463) | 1995-02 – 2000-04 | 75 | 102 | 2874 | |
| SPRINTER 3-t Van (B903) 311 CDI (903.661, 903.662, 903.663) | 2000-04 – 2006-05 | 80 | 109 | 2148 | |
| SPRINTER 3-t Van (B903) 311 CDI 4×4 (903.662, 903.663) | 2002-08 – 2006-05 | 80 | 109 | 2148 | |
| SPRINTER 3-t Van (B903) 312 D 2.9 (903.461, 903.462, 903.463) | 1995-02 – 2000-04 | 90 | 122 | 2874 | |
| SPRINTER 3-t Van (B903) 312 D 2.9 4×4 (903.461, 903.462) | 1997-05 – 2002-08 | 90 | 122 | 2874 | |
| SPRINTER 3-t Van (B903) 313 CDI (903.663, 903.662, 903.661) | 2000-04 – 2006-05 | 95 | 129 | 2148 | |
| SPRINTER 3-t Van (B903) 313 CDI 4×4 (903.662, 903.663) | 2002-08 – 2006-05 | 95 | 129 | 2148 | |
| SPRINTER 3-t Van (B903) 314 (903.061, 903.062, 903.063, 903.661, 903.662) | 1995-02 – 2006-05 | 105 | 143 | 2295 | |
| SPRINTER 3-t Van (B903) 314 4×4 (903.661, 903.662, 903.663) | 1995-02 – 2006-05 | 105 | 143 | 2295 | |
| SPRINTER 3-t Van (B903) 314 NGT (903.661, 903.061, 903.062, 903.063, 903.662) | 1995-02 – 2006-05 | 95 | 125 | 2295 | |
| SPRINTER 3-t Van (B903) 316 CDI (903.661, 903.662, 903.663) | 2000-04 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 3-t Van (B903) 316 CDI 4×4 (903.662, 903.663) | 2001-02 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 3-t Bus (B903) 308 CDI (903.671, 903.672, 903.673) | 2000-04 – 2006-05 | 60 | 82 | 2148 | |
| SPRINTER 3-t Bus (B903) 308 D (903.372, 903.373) | 1995-02 – 2000-04 | 58 | 79 | 2299 | |
| SPRINTER 3-t Bus (B903) 310 D 4×4 (903.472, 903.473) | 1997-05 – 2002-08 | 75 | 102 | 2874 | |
| SPRINTER 3-t Bus (B903) 311 CDI (903.671, 903.672) | 2000-04 – 2006-05 | 80 | 109 | 2148 | |
| SPRINTER 3-t Bus (B903) 311 CDI 4×4 (903.672, 903.673) | 2002-08 – 2006-05 | 80 | 109 | 2148 | |
| SPRINTER 3-t Bus (B903) 312 D 2.9 (903.471, 903.472, 903.473) | 1995-02 – 2000-04 | 90 | 122 | 2874 | |
| SPRINTER 3-t Bus (B903) 312 D 2.9 4×4 (903.473) | 1997-05 – 2002-08 | 90 | 122 | 2874 | |
| SPRINTER 3-t Bus (B903) 313 CDI (903.671, 903.672, 903.673) | 2000-04 – 2006-05 | 95 | 129 | 2148 | |
| SPRINTER 3-t Bus (B903) 313 CDI 4×4 (903.672, 903.673) | 2002-08 – 2006-05 | 95 | 129 | 2148 | |
| SPRINTER 3-t Bus (B903) 314 (903.071, 903.072, 903.073, 903.671, 903.672,… | 1995-02 – 2006-05 | 105 | 143 | 2295 | |
| SPRINTER 3-t Bus (B903) 314 4×4 (903.672, 903.673) | 1995-02 – 2006-05 | 105 | 143 | 2295 | |
| SPRINTER 3-t Bus (B903) 314 NGT (903.072, 903.671, 903.672) | 1995-02 – 2006-05 | 95 | 125 | 2295 | |
| SPRINTER 3-t Bus (B903) 316 CDI (903.671, 903.672, 903.673) | 2000-04 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 3-t Bus (B903) 316 CDI 4×4 (903.672, 903.673) | 2002-08 – 2006-05 | 115 | 156 | 2685 | |
| SPRINTER 3-t Platform/Chassis (B903) 308 CDI (903.611, 903.612, 903.613, 903.621, 903.622,… | 2000-04 – 2006-05 | 60 | 82 | 2148 | |
| SPRINTER 3-t Platform/Chassis (B903) 308 D 2.3 (903.311, 903.312, 903.322) | 1995-02 – 2000-04 | 58 | 79 | 2299 | |
| SPRINTER 3-t Platform/Chassis (B903) 308 D 2.3 (903.311, 903.322) | 1996-11 – 2000-04 | 60 | 82 | 2299 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.8 TDI | 2002-04 – 2006-07 | 116 | 158 | 2799 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.3 | 1996-06 – 2006-07 | 105 | 143 | 2295 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.5 SDI | 1996-09 – 2006-07 | 55 | 75 | 2461 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.5 TDI | 1996-06 – 1999-08 | 75 | 102 | 2461 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.5 TDI | 1999-05 – 2006-07 | 66 | 90 | 2461 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.5 TDI | 1999-05 – 2006-07 | 80 | 109 | 2461 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.8 TDI | 1997-07 – 2003-05 | 92 | 2798 | ||
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.5 TDI | 1999-05 – 2006-07 | 80 | 109 | 2461 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.8 TDI | 1997-07 – 2002-01 | 92 | 125 | 2799 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.8 TDI | 1999-01 – 2006-07 | 96 | 130 | 2799 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.5 TDI | 2001-05 – 2006-07 | 61 | 83 | 2461 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.5 TDI | 2001-05 – 2006-07 | 70 | 95 | 2461 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.3 | 1996-05 – 2006-07 | 105 | 143 | 2295 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.3 | 1996-05 – 2006-07 | 105 | 143 | 2295 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.5 SDI | 1996-09 – 2006-07 | 55 | 75 | 2461 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.5 TDI | 1996-05 – 1999-08 | 75 | 102 | 2461 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.5 TDI | 1999-05 – 2006-07 | 66 | 90 | 2461 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.5 TDI | 2001-05 – 2006-07 | 61 | 83 | 2461 | |
| LT 28-46 II Van (2DA, 2DD, 2DH) 2.5 TDI | 2001-05 – 2006-07 | 70 | 95 | 2461 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.8 TDI | 1997-07 – 2002-01 | 92 | 125 | 2799 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.8 TDI | 1999-01 – 2006-07 | 96 | 130 | 2799 | |
| LT 28-46 II Platform/Chassis (2DC, 2DF, 2DG, 2DL, 2DM) 2.8 TDI | 2002-04 – 2006-07 | 116 | 158 | 2799 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.5 SDI | 1996-07 – 2006-07 | 55 | 75 | 2461 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.5 TDI | 1996-05 – 1999-08 | 75 | 102 | 2461 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.5 TDI | 1999-05 – 2006-07 | 66 | 90 | 2461 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.5 TDI | 1999-05 – 2006-07 | 80 | 109 | 2461 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.5 TDI | 2001-05 – 2006-07 | 61 | 83 | 2461 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.5 TDI | 2001-05 – 2006-07 | 70 | 95 | 2461 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.8 TDI | 2001-05 – 2006-06 | 116 | 158 | 2799 | |
| LT 28-35 II Bus (2DB, 2DE, 2DK) 2.8 TDI | 1999-01 – 2002-01 | 96 | 131 | 2798 |
