Description
Specifications
| paired article number | 211406 |
| Fitting Position | Front Axle Left; behind the axle |
| Manufacturer Restriction | AKEBONO |
| Brake Caliper Type | Floating Caliper; Brake Caliper (1 piston) |
| Piston Diameter | 60 mm |
| for brake disc thickness | 22 mm |
| Brake Disc Type | Vented |
| for brake disc diameter | 257 mm |
| Material | Cast Iron |
| Net weight | 3.33 kg |
| Weight | 3.33 kg |
| Country of Origin | China |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| ISUZU | 894388-0170, 894438-6860, 894438-6861, 897065-3510, 94438686 |
| OPEL | 542049, 542277, 94388017, 97065351 |
| VAUXHALL | 94388017, 97065351 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| AKEBONO | B016-100 |
| ATE | 24.3601-1715.5 |
| BENDIX | 692846B |
| BOSCH | 0986473306 |
| BREMBO | F34002 |
| BUDWEG CALIPER | 341666 |
| Brake ENGINEERING | CA927 |
| CARDONE | 382846 |
| DELCO REMY | DC81666 |
| DELPHI | LC2104 |
| DRI | 3137400 |
| ELSTOCK | 82-0347 |
| FRIESEN | QBS2101 |
| FTE | RX609879A0 |
| GIRLING | 67934265 |
| HELLA | 8AC355393-791 |
| ISUZU | 894388-0170, 894438-6860, 894438-6861, 897065-3510, 94438686 |
| OPEL | 542049, 542277, 94388017, 97065351 |
| RE-EX | 506-01096 |
| SHAFTEC | BC183 |
| TMI | BR001096 |
| TRW | BHS1240E, BHS263E, BHS264 |
| UBD | 52258 |
| VAUXHALL | 94388017, 97065351 |
| sbs | 1301211405 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| D-MAX I (TFR, TFS) 2.5 DiTD 4×4 (TFS54) | 2002-05 – 2012-06 | 74 | 101 | 2499 | |
| CAMPO (KB) 2.2 D 4WD (KBD42, KBD47) | 1983-01 – 1990-12 | 39 | 53 | 2238 | |
| CAMPO (KB) 2.2 4WD | 1988-04 – 1988-12 | 66 | 2254 | ||
| TROOPER II (UB) 3.1 TD | 1991-08 – 1998-07 | 84 | 3059 | ||
| TROOPER I (UBS) 2.6 4WD | 1986-11 – 1991-07 | 85 | 2559 | ||
| TROOPER I Open Off-Road Vehicle (UBS) 2.2 D 4×4 | 1984-05 – 1989-07 | 39 | 53 | 2238 | |
| TROOPER II Open Off-Road Vehicle (UB) 3.2 | 1991-08 – 1998-07 | 130 | 177 | 3165 | |
| TROOPER I Open Off-Road Vehicle (UBS) 2.2 TD (UBS52) | 1984-03 – 1991-12 | 53 | 72 | 2238 | |
| TROOPER I Open Off-Road Vehicle (UBS) 2.3 (UBS16) | 1985-11 – 1991-12 | 66 | 90 | 2254 | |
| TROOPER I Open Off-Road Vehicle (UBS) 2.6 i (UBS17) | 1987-10 – 1991-12 | 85 | 116 | 2559 | |
| TROOPER II (UB) 3.2 | 1991-08 – 1998-07 | 130 | 177 | 3165 | |
| TROOPER I (UBS) 2.2 D 4WD | 1984-05 – 1989-12 | 39 | 53 | 2238 | |
| TROOPER I (UBS) 2.8 TD (UBS55) | 1987-10 – 1991-12 | 71 | 97 | 2771 | |
| TROOPER I (UBS) 2.8 TD (UBS55) | 1988-10 – 1991-12 | 78 | 106 | 2771 | |
| CAMPO (TF0, TF1) 2.3 4×4 (TFS16) | 1991-08 – 1994-08 | 69 | 94 | 2254 | |
| CAMPO (TF0, TF1) 2.3 4×4 (TFS16) | 1994-08 – 1996-09 | 72 | 98 | 2254 | |
| CAMPO (TF0, TF1) 2.5 D 4×4 (TFS54) | 1991-08 – 1994-06 | 56 | 76 | 2499 | |
| CAMPO (TF0, TF1) 2.5 DTI 4×4 | 2001-07 – 2001-12 | 74 | 101 | 2499 | |
| CAMPO (TF0, TF1) 2.5 TD 4×4 (TFS54) | 1994-07 – 2001-06 | 56 | 76 | 2499 | |
| CAMPO (TF0, TF1) 3.1 TD 4×4 (TFS69) | 1992-12 – 2001-06 | 80 | 109 | 3059 | |
| FRONTERA A (U92) 2.2 i (54MWL4) | 1995-03 – 1998-10 | 100 | 136 | 2198 | |
| FRONTERA A (U92) 2.3 TD (5JMWL4) | 1992-03 – 1998-10 | 74 | 100 | 2260 | |
| FRONTERA A (U92) 2.4 i (53MWL4) | 1992-03 – 1998-10 | 92 | 125 | 2410 | |
| FRONTERA A Sport (U92) 2.0 i (52SUD2, 55SUD2) | 1992-03 – 1998-10 | 85 | 115 | 1998 | |
| FRONTERA A Sport (U92) 2.5 TDS | 1996-09 – 1998-10 | 85 | 115 | 2499 | |
| FRONTERA A Sport (U92) 2.8 TD (5BSUD2) | 1995-03 – 1996-08 | 83 | 113 | 2771 | |
| FRONTERA A (U92) 2.0 i | 1993-05 – 1998-08 | 85 | 1998 | ||
| FRONTERA Mk I (A) (U92) 2.0 | 1995-04 – 1998-08 | 85 | 1998 |
