Description
Trailer Release Valve
Part Number: 9630010530
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Actuation | Black/Red |
| Application | 971 002 |
| Calculated Volume (dm³) | 1.7205 |
| Comments | With non-return valve |
| Distance between holes | 86 mm |
| Max. operating pressure | 8.5 bar |
| Mounting | 2x Ø 8.5 mm – Flange |
| Port thread 1-1 | M16 x 1.5 |
| Port thread 1-2 | M16 x 1.5 |
| Port thread 2 | Ø 21.5 mm |
| Port thread 21 | M16 x 1.5 |
| Port thread 22 | M16 x 1.5 |
| Port thread 3 | Flap Exhaust |
| Product category | Device |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Release valve |
| GTIN | 7895851081048 |
| Size (mm x mm x mm) | 178.5 x 94.5 x 102 |
| UPC | 193133371939 |
| Weight (kg) | 0.603 |
| Weight (lb) | 1.33 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 1519270 |
| KRONE | 58124231 |
| KRONE | 5812423 |
| KRONE | 505812423 |
| KÖGEL | 336490 |
| SCANIA | 2090267 |
| SCHMITZ CARGOBULL | 052190 |
| SCHMITZ CARGOBULL | 52190 |
| VOLVO | WA9630010530 |
