Description
Special Triple Cylinder compressor, flange mounted
Part Number: 912510303R
Technical Specifications
| Brand | ZF REMAN – WABCO |
| Part type | Remanufactured |
| Calculated Volume (dm³) | 46.2 |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 12.5 bar |
| Mounting | Flange mounting |
| Operating speed | 3000 (1/min) |
| Piston diameter | 85 mm |
| Piston stroke | 56 mm |
| Port thread 0 | Ø 25 mm |
| Port thread 2 | M26 x 1.5 |
| Port thread 4 | M10 x 1.0 |
| Port thread 8.1 | Ø 4 mm |
| Port thread 8.2 | Ø 15.5 mm |
| Port thread 9.1 | M16 x 1.5 |
| Port thread 9.2 | M16 x 1.5 |
| Product category | Device |
| Swept volume (cm³) | 636 cm3 |
| Technical specification | OE specification |
| Type | Twin Cylinder |
| GTIN | 04057875343745 |
| Size (mm x mm x mm) | 280 x 330 x 500 |
| UPC | 193133412816 |
| Weight (kg) | 32.5 |
| Weight (lb) | 71.65 |
OEM Cross References
| Brand | Reference No |
|---|---|
| EVOBUS | A4571303815 |
| MERCEDES-BENZ | 4571305015 |
| MERCEDES-BENZ | A4571305015 |
| MERCEDES-BENZ | 4571303815 |
| MERCEDES-BENZ | A4571303815 |
