Description
Single-Cylinder compressor, flange mounted
Part Number: 4111470660
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Calculated Volume (dm³) | 14.72 |
| Cooling | Water |
| Crankshaft thread | M20 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Max. operating pressure | 10.0 bar |
| Mounting | Flange mounting |
| Operating speed | 3000 (1/min) |
| Piston diameter | 90.0 mm |
| Piston stroke | 46 mm |
| Port thread 0 | M26 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Port thread 8.1 | M10 x 1 |
| Port thread 9.1 | M22 x 1.5 |
| Port thread 9.2 | M22 x 1.5 |
| Product category | Device |
| Swept volume (cm³) | 293 cm3 |
| Technical specification | OE specification |
| Type | Single Cylinder |
| Type of operation | Normal pressure using unloader |
| GTIN | 04057875155928 |
| Size (mm x mm x mm) | 320 x 200 x 230 |
| UPC | 193133478454 |
| Weight (kg) | 12.83 |
| Weight (lb) | 28.2853 |
OEM Cross References
| Brand | Reference No |
|---|---|
| LIEBHERR | 5700161 |
