Description
Servo Clutch
Part Number: 9700511590
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Calculated Volume (dm³) | 6.4865 |
| Comments | MB G4 |
| Distance between holes | 146 mm |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 188 mm |
| Max. operating pressure | 8.0 bar |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 2x Ø 11.0 mm |
| Port thread 1-4 | M14 x 1.5 ( K ) |
| Port thread 11 | M16 x 1.5 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Product category | Device |
| Push-rod thread | Hole Ø 12.0 mm |
| Stroke | 75.0 mm |
| Technical specification | OE specification |
| Temperature range | -20°C to +140°C |
| GTIN | 7895851053168 |
| Size (mm x mm x mm) | 260 x 189 x 132 |
| UPC | 193133373292 |
| Weight (kg) | 2.812 |
| Weight (lb) | 6.1994 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 1518252 |
| EVOBUS | A0002951418 |
| MERCEDES-BENZ | 0002951418 |
| MERCEDES-BENZ | A0002951418 |
| MERCEDES-BENZ | 0002950918 |
