Description
Pedal Unit without Clutch
Part Number: 9650010550
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Application | DAF |
| Calculated Volume (dm³) | 65.36 |
| Electrical connection | Tyco C-114-18740-1 Rev “D” |
| Max. operating pressure | 12.5 bar |
| Port thread 11 | Voss 232 NG8 |
| Port thread 12 | Voss 232 NG8 |
| Port thread 2 | M14 x 1.5 |
| Port thread 21 | Voss 230 NG8 |
| Port thread 22 | Voss 232 NG8 |
| Port thread 3 | Integrated silencer |
| Product category | Device |
| Stroke | 85/135 mm |
| Technical specification | OE specification |
| Temperature range | -35°C to +70°C |
| Type | Brake Pedal and Clutch Pedal |
| Voltage | 24 V |
| GTIN | 04057875299158 |
| Size (mm x mm x mm) | 430 x 380 x 400 |
| UPC | 193133416166 |
| Weight (kg) | 7.169 |
| Weight (lb) | 15.8 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 1845530 |
| DAF | 1974276 |
