Description
Park Release Emergency Valve
Part Number: 9710029000
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Calculated Volume (dm³) | 4.1 |
| Color | Black/Red |
| Comments | With plate 9710021034 |
| Max. operating pressure | 10.0 bar |
| Port thread 1-1 | M16 x 1.5 JED-152 |
| Port thread 1-2 | M16 x 1.5 JED – 152 |
| Port thread 21 | M16 x 1.5 JED – 152 |
| Port thread 22 | M16 x 1.5 JED – 152 |
| Port thread 4 | M16 x 1.5 JED – 152 |
| Product category | Device |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Version | Without test connection |
| GTIN | 7895851070400 |
| Size (mm x mm x mm) | 174 x 172 x 137 |
| UPC | 193133449911 |
| Weight (kg) | 1.57 |
| Weight (lb) | 3.4613 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 1518261 |
| DOLL | 7086972 |
| EGSA | 2402000104 |
| FAYMONVILLE | 64047 |
| FELDBINDER | 1026483 |
| GOLDHOFER | 168783 |
| HÜFFERMANN | 6BE00210100 |
| IBIPORA | 3051000114 |
| KENWORTH | S971-002-900-0 |
| KODAIRA | VS70000149 |
| KRONE | 5817911 |
| KRONE | 58179110 |
| KÄSSBOHRER | 8283021000 |
| KÄSSBOHRER | 21150110052 |
| KÖGEL | 361687 |
| KÖGEL | 22361687 |
| LANGENDORF | 1240051 |
| LIEBHERR | 10167537 |
| LIESS | 3801011644 |
| LINSHALM | 68587 |
| LOHR | A05021220 |
| MACK | 2S9710029000 |
| MACK | 2S971 002 900 0 |
| MACK | 6300-9710029000 |
| MAN | ZG046540002 |
| MANOS | 2157 |
| MERITOR | S9710029000 |
| NIPPON SHARYO | A3000JC15901 |
| NIPPON TREX | 912002-00012 |
| NOMA | 9213005 |
| NOOTEBOOM | 2090150 |
| NOOTEBOOM | 400712115 |
| OTOKAR | AIF1164 |
| PACCAR | 1518261 |
| PASTRE | 931160602 |
| PETERBILT | S971-002-900-0 |
| ROSSETTI | 700840230 |
| SCANIA | 1738468 |
| SCHMITZ CARGOBULL | 8283021000 |
| SCHMITZ CARGOBULL | INS0120079 |
| SCHMITZ CARGOBULL | 1060744 |
| SCHWARZMÜLLER | 60950 |
| TIRSAN | 21150110052 |
| TRUCKVAN | 1123000021 |
| VAN HOOL | 10950969 |
| VOLVO | WA9710029000 |
| VOLVO | WAB9710029000 |
