Description
Levelling Valve
Part Number: 4640070010
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Actuation angle | -19° to +19° |
| Calculated Volume (dm³) | 0.489 |
| Distance between holes | 46.4 mm |
| Length | R 201 mm |
| Max. operating pressure | 11.0 bar |
| Mounting | 2x Ø 8.5 mm |
| Port thread 1 | Quick Connection Ø 6 mm |
| Port thread 2 | Quick Connection Ø 6 mm |
| Product category | Component |
| Stroke of lever | ±30° |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | With Lever |
| Type of operation | Hole-lever Ø 6.5 mm |
| Version | With one-way valve |
| GTIN | 04057875214922 |
| Size (mm x mm x mm) | 65 x 215 x 35 |
| UPC | 193133308386 |
| Weight (kg) | 0.211 |
| Weight (lb) | 0.46517 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 0759050 |
| DAF | 759050 |
| DAF | 1505081 |
| DEUTZ | 04432191 |
| DEUTZ | 4432191 |
| ERF | 4134534 |
| FAW | 5001320Q824A |
| FAW | 5001075CA01A |
| FAW | 5001075CA01C00B |
| FAW | 5001075CA01 |
| FAW | 5001320-Q824A |
| FORD | 3C465C100AA |
| IRISBUS | 8188642 |
| IVECO | 08188642 |
| IVECO | 8188642 |
| JAC | 64006-Y4010XZ |
| KÖGEL | 332419 |
| MAN | 81436106129 |
| MAN | 4134534 |
| NEOPLAN | 81436106129 |
| PACCAR | 1505081 |
| RENAULT | 5010136105 |
| RENAULT | 5021170189 |
| SCANIA | 1934938 |
| SINOTRUK (CNHTC) | WG1642440051 |
| SINOTRUK (CNHTC) | WG1642440051/1 |
| SINOTRUK (CNHTC) | WG16424400511 |
| TATRA | 4640070010 |
