Description
Hose 13×6, 40 m, DIN 74310
Part Number: 8288764136
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Body material | Rubber |
| Calculated Volume (dm³) | 54.9 |
| Color | Black/Black |
| Comments | Smooth |
| Diameter | 13.0 x 6.0 mm, 13.0 mm |
| Inner diameter | 13.0 mm |
| Length | 40.0 m |
| Max. operating pressure | 10.0 bar |
| Outer diameter | 25.0 mm |
| Product category | Component |
| Technical specification | OE specification |
| Temperature range | -40°C to +70°C |
| Tube diameter | 13 x 6 mm |
| Type | Ø 13.0 x 6.0 mm |
| Version | Without fittings |
| GTIN | 04057875246275 |
| Size (mm x mm x mm) | 538 x 526 x 194 |
| UPC | 193133342748 |
| Weight (kg) | 19.2 |
| Weight (lb) | 42.3287 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 1506269 |
| DAF | 1519661 |
| JOHN DEERE | 2480011 |
| JOHN DEERE | WZ2480011 |
| LANGENDORF | 1131118NEU |
| NOOTEBOOM | 0366007 |
| SCANIA | 1912294 |
| SCANIA | 1912340 |
| SCHMITZ CARGOBULL | 1060756 |
| SCHWARZMÜLLER | 2430 |
