Description
Duomatic
Part Number: 4528020090
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Application | Towing vehicle |
| Calculated Volume (dm³) | 1.8977 |
| Comments | With german ABE certificate |
| Max. operating pressure | 10.0 bar |
| Mounting | 452 802 100 4 |
| Port thread 1 | M16 x 1.5 |
| Port thread 4 | M22 x 1.5 |
| Port threads | M16 x 1.5 |
| Product category | Device |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Towing vehicle / drawbar trailer |
| Version | With lever |
| GTIN | 04057875207511 |
| Size (mm x mm x mm) | 227 x 88 x 95 |
| UPC | 193133441977 |
| Weight (kg) | 1.127 |
| Weight (lb) | 2.4846 |
OEM Cross References
| Brand | Reference No |
|---|---|
| DAF | 1325341 |
| DAF | 1504952 |
| DOLL | 8143161 |
| EVOBUS | 82855630000 |
| EVOBUS | A0004294530 |
| EVOBUS | A0004200258 |
| EVOBUS | 8285563000 |
| EVOBUS | 8285384000 |
| FAYMONVILLE | 5054 |
| FELDBINDER | 070045 |
| GREAT DANE | 2S4528020090 |
| IVECO | 41285154 |
| KALMAR IRION | 1718010327 |
| KALMAR IRION | 9217460001 |
| KEMPF | 2113022 |
| KOMATSU | 41616940 |
| KRONE | 5009454121 |
| KRONE | 500945412 |
| KRONE | 945412 |
| KÄSSBOHRER | 21151199017 |
| KÖGEL | 76624 |
| LANGENDORF | 1110972 |
| LOHR | L60090012 |
| MAFI | 0005670022 |
| MAN | 81512206120 |
| MAN | ZG045790002 |
| MERCEDES-BENZ | 0004294530 |
| MERCEDES-BENZ | A0004294530 |
| MERCEDES-BENZ | A0004200258 |
| MERITOR | S4528020090 |
| NEOPLAN | 81512206120 |
| NOOTEBOOM | 307023 |
| NOOTEBOOM | 05658 |
| ORTHAUS | 462010 |
| PACCAR | 1325341 |
| RENAULT | 5010458510 |
| SCANIA | 1912326 |
| SCANIA | 1853175 |
| SCANIA | 373397 |
| SCHMITZ CARGOBULL | 051428 |
| SCHMITZ CARGOBULL | 51428 |
| SCHMITZ CARGOBULL | INS0240008 |
| SCHWARZMÜLLER | 24249 |
| SOLARIS | 1102219250 |
| TEREX | 41616940 |
| TIRSAN | 21151199017 |
| VAN HOOL | 10562979 |
| VAN HOOL | 10519611 |
| VOLVO | WA4528020090 |
| VOLVO | 6213539 |
