Description
Clutch Servo
Part Number: 9700514730
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Calculated Volume (dm³) | 7.742 |
| Distance between holes | 130 mm |
| Important information | Please follow the installation instructions of the vehicle manufacturer |
| Length | 371 mm |
| Max. operating pressure | 10.0 bar |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 |
| Port thread 11 | M16 x 1.5 JED – 464 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Product category | Device |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 75.0 mm |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| GTIN | 04057875300465 |
| Size (mm x mm x mm) | 371 x 141 x 148 |
| UPC | 193133374060 |
| Weight (kg) | 2.715 |
| Weight (lb) | 5.986 |
OEM Cross References
| Brand | Reference No |
|---|---|
| BEIBEN | 8182940007 |
| FOTON | 1693016205010 |
| FOTON | 1432116280002 |
| HIGER | 16MC1-04010-C1 |
| KING LONG | 16MC104010C1 |
| SINOTRUK (CNHTC) | WG9725230041/4 |
| SINOTRUK (CNHTC) | WG97252300412 |
| SINOTRUK (CNHTC) | WG97252300512 |
| SINOTRUK (CNHTC) | WG8701230003 |
| SINOTRUK (CNHTC) | WG9725230041/2 |
| SUNWIN | SWB413650025 |
| ZHONGTONG | 1609-10-00021 |
