Description
Add-On ABS
Part Number: 4784071440
Technical Specifications
| Brand | WABCO |
| Part type | Premium original quality |
| Calculated Volume (dm³) | 5.3721 |
| Distance between holes | 112×108/90 mm |
| Medium | Brake fluid FMVSS 116 |
| Mounting | 3 x 3/8″ – 16 UNC-2B |
| Port thread FL | 7/16″ – 24 UNS-2B |
| Port thread FR | 1/2″ – 20 UNF-2B |
| Port thread MF | 7/16″ – 24 UNS – 2B |
| Port thread MR | 1/2″ – 20 UNF-2B |
| Port thread RL | 7/16″ – 24 UNS-2B |
| Port thread RR | 1/2″ – 20 UNF-2B |
| Product category | Device |
| Protection class | IP 6K9K |
| Technical specification | OE specification |
| Temperature range | -40°C to +85°C |
| Voltage | 12 V |
| GTIN | 04057875311768 |
| Size (mm x mm x mm) | 179 x 183 x 164 |
| UPC | 193133316367 |
| Weight (kg) | 5.448 |
| Weight (lb) | 12.011 |
