Description
Specifications
| Inner brake drum diameter | 203 mm |
| Inner brake drum height | 37 mm |
| Total brake drum height | 54 mm |
| Rim Hole Number | 5 |
| Wheel Hub Diameter | 76 mm |
| Outer brake drum diameter | 253 mm |
| Bolt Hole Circle Ø | 114.3 mm |
| Weight | 4.16 kg |
| Country of Origin | Netherlands |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| HYUNDAI | 584113X000 |
| KIA | 584113X000 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| BRECO | BT 1207 |
| BREMBO | 14.E275.20 |
| DELPHI | BF613 |
| HYUNDAI | 584113X000 |
| KAVO PARTS | BD-3377 |
| KAWE | 7D0744 |
| KIA | 584113X000 |
| LPR | 7D0744 |
| TRW | RPTA02410 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| ELANTRA V Saloon (MD, UD) 1.8 | 2010-09 – 2016-12 | 110 | 1797 | ||
| ELANTRA VI Saloon (AD, ADA) 1.6 | 2016-02 – 2020-12 | 94 | 1591 | ||
| ELANTRA V Saloon (MD, UD) 1.6 | 2011-04 – 2016-04 | 94 | 128 | 1591 | |
| ELANTRA V Saloon (MD, UD) 1.6 CRDi | 2011-02 – 2015-12 | 94 | 128 | 1582 | |
| ELANTRA V Saloon (MD, UD) 1.6 | 2011-06 – 2015-12 | 97 | 132 | 1591 | |
| CERATO KOUP III (YD) 2.0 CVVT | 2016-03 – … | 118 | 1999 | ||
| CERATO IV Saloon (BD, BDM) 1.6 MPi | 2018-02 – … | 94 | 1591 | ||
| CERATO IV Saloon (BD, BDM) 2.0 MPi | 2018-02 – … | 110 | 1999 |
