Description
Specifications
| Inner brake drum diameter | 254 mm |
| Inner brake drum height | 57 mm |
| Total brake drum height | 76 mm |
| Rim Hole Number | 5 |
| Wheel Hub Diameter | 66 mm |
| Outer brake drum diameter | 303 mm |
| Bolt Hole Circle Ø | 114.3 mm |
| Weight | 8.924 kg |
| Country of Origin | Netherlands |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| LAND ROVER | SDC000010 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| APEC | BDR9020, DRM9955 |
| ASHIKA | 56-0L-L04 |
| ATE | 24.0225-4020.1, 480310 |
| BENDIX | 329268B |
| BLUE PRINT | ADJ134702 |
| BORG & BECK | BBR7211 |
| BOSCH | 0 986 477 227 |
| BRECO | BT 1161 |
| BREMBO | 14.C010.10 |
| BREMSI | CR5855 |
| Brake ENGINEERING | DR962373 |
| DELPHI | BF513 |
| FEBI BILSTEIN | 171124 |
| FERODO | FDR329268 |
| FREMAX | BD-1185 |
| HELLA | 8DT 355 301-731 |
| JAPANPARTS | TA-L04, TA-L04C, TAL04JM |
| JAPKO | 56L04, 56L04C |
| JURID | 329268J |
| KAWE | 7D0670, 7D0670R |
| LAND ROVER | SDC000010 |
| LPR | 7D0670, 7D0670R |
| MAXGEAR | 19-3698 |
| METELLI | 18-0413 |
| MINTEX | MBD332 |
| NK | 251213 |
| National | NDR360 |
| OMC | 100400FN |
| OPTIMAL | BT-1930 |
| PAGID | 61331 |
| PEMEBLA | BNXBDM1089, JAPTA-L04, JAPTA-L04C, JAPTAL04JM |
| QUINTON HAZELL | BDR655 |
| RIDEX | 123B0125 |
| SWAG | 33 10 2744 |
| TEXTAR | 94032800 |
| TRISCAN | 8120 17208, 8120 17208C |
| TRW | DB4384 |
| VEMA | 801504 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| FREELANDER I (L314) 2.0 Td4 4×4 | 2000-11 – 2006-10 | 82 | 112 | 1951 | |
| FREELANDER I (L314) 2.0 Td4 4×4 | 2001-03 – 2006-10 | 80 | 109 | 1951 | |
| FREELANDER I (L314) 2.5 V6 4×4 | 2000-11 – 2006-10 | 130 | 177 | 2497 | |
| FREELANDER I Soft Top (L314) 1.8 4×4 | 2000-10 – 2006-10 | 86 | 1796 | ||
| FREELANDER I Soft Top (L314) 2.0 TD4 4×4 | 2000-10 – 2006-10 | 82 | 1951 | ||
| FREELANDER I Soft Top (L314) 2.5 V6 4×4 | 2000-11 – 2006-10 | 130 | 2497 | ||
| FREELANDER I (L314) 1.8 16V 4×4 | 1998-04 – 2006-10 | 86 | 117 | 1796 | |
| FREELANDER I (L314) 1.8 i 16V 4×4 | 1998-02 – 2000-11 | 88 | 120 | 1796 | |
| FREELANDER I Soft Top (L314) 1.8 i 16V 4×4 | 1998-02 – 2006-10 | 88 | 120 | 1796 |
