Description
Specifications
| Joint Type | CV Joint |
| External Toothing wheel side | 27 |
| Internal Toothing wheel side | 25 |
| Number of Teeth, ABS ring | 47 |
| ABS-Ring Diameter | 102 mm |
| Seal Ring Diameter | 60 mm |
| Machined | with groove in internal component |
| Joint Diameter | 84 mm |
| Thread Size | M22x1.5 |
| Bellows Material | NBR (nitrile butadiene rubber) |
| New Part | |
| Supplementary Article/Supplementary Info | with grease |
| Weight | 1.962 kg |
| Country of Origin | Italy |
| Customs Code | 870899 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| HYUNDAI | 4950038400, 4950038401, 4950038402, 49501-3A210 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| GSP | 824029 |
| HYUNDAI | 4950038400, 4950038401, 4950038402, 49501-3A210, LÖBRO, 305463 |
| SKF | VKJA5920 |
| TrakMotive | 40-0210 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| SONATA IV (EF) 2.0 16V | 2001-10 – 2004-11 | 106 | 1997 | ||
| SONATA IV (EF) 2.0 16V | 2001-10 – 2004-11 | 96 | 131 | 1997 | |
| SONATA IV (EF) 2.0 16V | 1998-06 – 2001-10 | 100 | 136 | 1997 | |
| SONATA IV (EF) 2.4 16V | 1998-03 – 2001-10 | 105 | 143 | 2351 | |
| SONATA IV (EF) 2.7 V6 | 2001-10 – 2004-11 | 127 | 173 | 2656 | |
| TRAJET (FO) 2.0 | 2001-03 – 2003-10 | 103 | 1997 | ||
| TRAJET (FO) 2.0 | 2000-03 – 2008-07 | 100 | 136 | 1997 | |
| TRAJET (FO) 2.0 | 2004-01 – 2008-07 | 103 | 140 | 1975 | |
| MAGENTIS I (GD, MS) 2.0 | 2001-05 – 2005-09 | 100 | 136 | 1997 |
