Description
Specifications
| External Toothing wheel side | 28 |
| External Toothing differential side | 36 |
| Number of Teeth, ABS ring | 48 |
| ABS-Ring Diameter | 104 mm |
| Seal Ring Diameter | 59 mm |
| Wheel-sided joint diameter | 101 mm |
| Transmission-sided joint diameter | 95 mm |
| Thread Size | M24x2.0 |
| Exchange Part | |
| Weight | 9.556 kg |
| Country of Origin | Italy |
| Customs Code | 870899 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| FORD | 1495673, 6C113B437DD, 6C113B437DE |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| FORD | 1495673, 6C113B437DD, 6C113B437DE, LÖBRO, 305403 |
| SERCORE | 121165 |
| TrakMotive | 30-0407 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.2 TDCi | 2006-04 – 2014-08 | 81 | 110 | 2198 | |
| TRANSIT Platform/Chassis (FM_ _, FN_ _, FF_ _) 2.2 TDCi | 2006-04 – 2014-08 | 96 | 130 | 2198 | |
| TRANSIT TOURNEO Bus 2.2 TDCi | 2006-07 – 2014-08 | 96 | 131 | 2198 | |
| TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi | 2006-04 – 2014-08 | 81 | 110 | 2198 | |
| TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi | 2006-04 – 2014-08 | 96 | 130 | 2198 | |
| TRANSIT TOURNEO Bus 2.2 TDCi | 2006-07 – 2014-08 | 81 | 110 | 2198 | |
| TRANSIT Van (FA_ _) 2.2 TDCi | 2006-04 – 2014-08 | 81 | 110 | 2198 | |
| TRANSIT Van (FA_ _) 2.2 TDCi | 2006-04 – 2014-08 | 96 | 130 | 2198 |
