Description
Specifications
| paired article number | 2136227 |
| Fitting Position | Front Axle Right; in front of axle |
| Manufacturer Restriction | BOSCH |
| Brake Caliper Type | Floating Caliper; Brake Caliper (1 piston) |
| Piston Diameter | 48 mm |
| for brake disc thickness | 17 mm |
| Brake Disc Type | Vented |
| for brake disc diameter | 253 mm |
| Material | Cast Iron |
| Net weight | 2.54 kg |
| Weight | 2.54 kg |
| Country of Origin | China |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| OPEL | 4706757, 55103-84E00, 9214007 |
| SUBARU | 5510384E00 |
| SUZUKI | 55103-84E00, 5510384 |
| VAUXHALL | 9214007 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| BOSCH | 0986474343 |
| BREMBO | F59153 |
| BUDWEG CALIPER | 343289 |
| Brake ENGINEERING | CA2473R |
| CARDONE | 385035 |
| DELCO REMY | DC83289 |
| DRI | 3286000 |
| ELSTOCK | 83-0806 |
| FTE | RX489856A0 |
| HELLA | 8AC355387-841 |
| OPEL | 4706757, 55103-84E00, 9214007 |
| RE-EX | 506-02431 |
| SUBARU | 5510384E00 |
| SUZUKI | 55103-84E00, 5510384 |
| TMI | BR002431 |
| TRW | BHV613E |
| VAUXHALL | 9214007 |
| sbs | 13012136228 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| AGILA A (H00) 1.0 (F68) | 2003-08 – 2007-12 | 44 | 60 | 998 | |
| AGILA A (H00) 1.0 12V (F68) | 2000-09 – 2007-12 | 43 | 58 | 973 | |
| AGILA A (H00) 1.2 16V (F68) | 2000-09 – 2007-12 | 55 | 75 | 1199 | |
| AGILA A (H00) 1.2 16V Twinport (F68) | 2004-07 – 2007-12 | 59 | 80 | 1229 | |
| AGILA A (H00) 1.3 CDTI (F68) | 2003-08 – 2007-12 | 51 | 70 | 1248 | |
| JUSTY III (G3X) 1.3 CDTi | 2003-12 – 2007-08 | 51 | 1248 | ||
| JUSTY III (G3X) 1.3 AWD (G3X413) | 2003-09 – … | 69 | 94 | 1328 | |
| JUSTY III (G3X) 1.5 AWD (G3X413) | 2003-09 – … | 73 | 99 | 1490 | |
| IGNIS II (MH) 1.3 (RM413) | 2003-09 – … | 69 | 94 | 1328 | |
| IGNIS II (MH) 1.3 4×4 (RM413) | 2003-09 – … | 69 | 94 | 1328 | |
| IGNIS II (MH) 1.3 DDiS (RM413D) | 2003-09 – … | 51 | 70 | 1248 | |
| IGNIS II (MH) 1.5 (RM415) | 2003-09 – … | 73 | 99 | 1490 | |
| IGNIS II (MH) 1.5 4×4 (RM415) | 2003-09 – … | 73 | 99 | 1490 | |
| WAGON R (MH21, MH22) 1.3 (RB413) | 2003-09 – 2010-12 | 65 | 1328 | ||
| WAGON R+ (MA) 1.2 (RB 412) | 2005-01 – 2008-12 | 59 | 1229 | ||
| WAGON R+ (MA) 1.3 (RB413) | 2003-09 – 2006-08 | 69 | 94 | 1328 | |
| WAGON R+ (MA) 1.3 4WD (RB413) | 2003-09 – … | 69 | 94 | 1328 | |
| WAGON R+ (MA) 1.3 DDiS (RB413D) | 2003-09 – … | 51 | 70 | 1248 |
