Description
Specifications
| paired article number | 2136152 |
| Fitting Position | Front Axle Left; in front of axle |
| Manufacturer Restriction | ATE |
| Brake Caliper Type | Floating Caliper; Brake Caliper (1 piston) |
| Piston Diameter | 54 mm |
| for brake disc thickness | 24 mm |
| Brake Disc Type | Vented |
| for brake disc diameter | 258 mm |
| Material | Cast Iron |
| Net weight | 2.9 kg |
| Weight | 3.257 kg |
| Country of Origin | China |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| CHEVROLET | 90297775, 90487045 |
| OPEL | 542233, 542269, 90297775, 90487045 |
| VAUXHALL | 90297775, 90487045 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| ATE | 11.3541-8095.2 |
| BENDIX | 692305B |
| BOSCH | 0986473913 |
| BREMBO | F59072 |
| BUDWEG CALIPER | 341822 |
| Brake ENGINEERING | CA761 |
| CARDONE | 382305 |
| CHEVROLET | 90297775, 90487045 |
| DELCO REMY | DC81822 |
| DELPHI | LC3460 |
| DRI | 3145400 |
| ELSTOCK | 82-0445 |
| FRIESEN | QBS3193 |
| FTE | RX541307A0 |
| GIRLING | 32933178 |
| HELLA | 8AC355388-931 |
| OPEL | 542233, 542269, 90297775, 90487045 |
| RE-EX | 506-01366 |
| TMI | BR001366 |
| TRW | BHW175, BHW175E |
| TTV | TBS81822 |
| UBD | 50280 |
| VAUXHALL | 90297775, 90487045 |
| sbs | 13012136151 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| CALIBRA A (C89) 2.0 i 16V 4×4 (M07) | 1990-06 – 1994-02 | 110 | 150 | 1998 | |
| CALIBRA A (C89) 2.0 i 16V 4×4 (M07) | 1994-02 – 1997-07 | 100 | 136 | 1998 | |
| CALIBRA A (C89) 2.0 i 4×4 (M07) | 1990-06 – 1997-07 | 85 | 115 | 1998 | |
| CALIBRA A (C89) 2.0 i Turbo 4×4 (M07) | 1991-08 – 1997-07 | 150 | 204 | 1998 | |
| OMEGA A (V87) 1.8 (F19, M19, N19) | 1987-09 – 1994-03 | 65 | 88 | 1796 | |
| OMEGA A (V87) 1.8 (F19, M19, N19) | 1986-09 – 1994-03 | 85 | 115 | 1796 | |
| OMEGA A (V87) 1.8 N (F19, M19, N19) | 1986-09 – 1987-08 | 60 | 82 | 1796 | |
| OMEGA A (V87) 1.8 S (F19, M19, N19) | 1986-09 – 1994-03 | 66 | 90 | 1796 | |
| OMEGA A (V87) 2.0 (F19, M19, N19) | 1986-09 – 1994-03 | 90 | 122 | 1998 | |
| OMEGA A (V87) 2.0 (F19, M19, N19) | 1990-09 – 1994-03 | 74 | 100 | 1998 | |
| OMEGA A (V87) 2.0 (F19, M19, N19) | 1990-09 – 1994-03 | 73 | 99 | 1998 | |
| OMEGA A (V87) 2.0 i (F19, M19, N19) | 1986-09 – 1994-03 | 85 | 115 | 1998 | |
| OMEGA A (V87) 2.4 i (F19, M19, N19) | 1988-09 – 1994-03 | 92 | 125 | 2410 | |
| OMEGA A (V87) 2.6 i (F19, M19, N19) | 1990-09 – 1994-03 | 110 | 150 | 2594 | |
| OMEGA A (V87) 3.0 (3000) (F19, M19, N19) | 1987-03 – 1987-12 | 115 | 156 | 2969 | |
| OMEGA A Estate (V87) 1.8 (F35, M35) | 1987-09 – 1994-03 | 65 | 88 | 1796 | |
| OMEGA A Estate (V87) 1.8 (F35, M35) | 1986-09 – 1994-03 | 85 | 115 | 1796 | |
| OMEGA A Estate (V87) 1.8 S (F35, M35) | 1986-09 – 1994-03 | 66 | 90 | 1796 | |
| OMEGA A Estate (V87) 2.0 (F35, M35) | 1986-09 – 1994-03 | 90 | 122 | 1998 | |
| OMEGA A Estate (V87) 2.0 (F35, M35) | 1990-09 – 1994-03 | 74 | 100 | 1998 | |
| OMEGA A Estate (V87) 2.0 i (F35, M35) | 1990-09 – 1994-03 | 73 | 99 | 1998 | |
| OMEGA A Estate (V87) 2.0 i (F35, M35) | 1986-09 – 1994-04 | 85 | 115 | 1998 | |
| OMEGA A Estate (V87) 2.3 D (F35, M35) | 1986-09 – 1994-03 | 54 | 73 | 2260 | |
| OMEGA A Estate (V87) 2.3 TD (F35, M35) | 1986-09 – 1988-08 | 66 | 90 | 2260 | |
| OMEGA A Estate (V87) 2.3 TD Interc. (F35, M35) | 1988-09 – 1994-03 | 74 | 100 | 2260 | |
| OMEGA A Estate (V87) 2.4 i (F35, M35) | 1988-09 – 1994-03 | 92 | 125 | 2410 | |
| OMEGA A Estate (V87) 2.6 i (F35, M35) | 1990-09 – 1994-03 | 110 | 150 | 2594 | |
| OMEGA A Estate (V87) 3.0 (F35, M35) | 1987-03 – 1994-03 | 115 | 156 | 2969 | |
| OMEGA A Estate (V87) 3.0 (F35, M35) | 1987-03 – 1990-09 | 130 | 177 | 2969 | |
| OMEGA A Estate (V87) 3.0 24V (F35, M35) | 1989-09 – 1994-03 | 147 | 200 | 2969 | |
| OMEGA A Estate (V87) 3.0 Cat (F35, M35) | 1987-03 – 1994-03 | 130 | 177 | 2969 | |
| OMEGA A Estate (V87) 2.0 (F35, M35) | 1987-09 – 1994-04 | 85 | 1998 | ||
| OMEGA A (V87) 2.3 D (F19, M19, N19) | 1986-10 – 1994-03 | 54 | 73 | 2260 | |
| OMEGA A (V87) 2.3 TD (F19, M19, N19) | 1986-10 – 1988-08 | 66 | 90 | 2260 | |
| OMEGA A (V87) 2.3 TD Interc. (F19, M19, N19) | 1988-08 – 1994-03 | 74 | 100 | 2260 | |
| OMEGA A (V87) 3.0 24V (3000) (F19, M19, N19) | 1989-09 – 1994-03 | 147 | 200 | 2969 | |
| OMEGA A (V87) 3.0 24V (3000) (F19, M19, N19) | 1989-09 – 1994-03 | 150 | 204 | 2969 | |
| OMEGA A (V87) 3.0 24V Evolution500 (F19, M19, N19) | 1991-03 – 1992-07 | 169 | 230 | 2969 | |
| OMEGA A (V87) 3.0 (3000) (F19, M19, N19) | 1987-03 – 1990-09 | 130 | 177 | 2969 | |
| OMEGA A (V87) 3.0 (3000) Cat (F19, M19, N19) | 1988-03 – 1994-03 | 130 | 177 | 2969 | |
| OMEGA A (V87) 3.6 24V Lotus (F19, M19, N19) | 1990-08 – 1992-09 | 277 | 377 | 3638 | |
| OMEGA A Estate (V87) 1.8 N (F35, M35) | 1986-09 – 1987-08 | 60 | 82 | 1796 | |
| VECTRA A (J89) 2000 16V 4×4 (F19, M19) | 1989-01 – 1990-10 | 110 | 150 | 1998 | |
| VECTRA A (J89) 1.8 S 4×4 (F19, M19) | 1989-01 – 1989-07 | 65 | 88 | 1796 | |
| VECTRA A (J89) 2.0 (F19, M19) | 1988-09 – 1989-09 | 74 | 100 | 1998 | |
| VECTRA A (J89) 2.0 i 4×4 (F19, M19) | 1989-01 – 1990-10 | 85 | 115 | 1998 | |
| VECTRA A (J89) 2.0 i 4×4 (F19, M19) | 1989-08 – 1992-07 | 95 | 129 | 1998 | |
| VECTRA A (J89) 2.0 i Cat 4×4 (F19, M19) | 1989-01 – 1995-11 | 85 | 116 | 1998 | |
| VECTRA A (J89) 2.0 i Turbo 4×4 (F19, M19) | 1994-06 – 1995-11 | 150 | 204 | 1998 | |
| VECTRA A Hatchback (J89) 2.0 (F68, M68) | 1988-04 – 1989-09 | 74 | 100 | 1998 | |
| VECTRA A (J89) 2000/GT 16V Cat 4×4 (F19, M19) | 1990-02 – 1995-11 | 110 | 150 | 1998 | |
| VECTRA A (J89) 2.0 i 16V 4×4 (F19, M19) | 1994-06 – 1995-11 | 100 | 136 | 1998 |
