Description
Specifications
| paired article number | 2136103 |
| Fitting Position | Front Axle Right; in front of axle |
| Manufacturer Restriction | BOSCH |
| Brake Caliper Type | Floating Caliper; Brake Caliper (2 pistons) |
| Piston Diameter | 45 mm |
| for brake disc thickness | 24 mm |
| Brake Disc Type | Vented |
| for brake disc diameter | 280 mm |
| Material | Cast Iron |
| Net weight | 4.91 kg |
| Weight | 4.955 kg |
| Country of Origin | China |
| Customs Code | 870830 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| OPEL | 4501215, 7701205764, 9161515 |
| RENAULT | 7701205764 |
| VAUXHALL | 9161515 |
| VOLVO | 8111959 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| BOSCH | 0204102731, 0204103731 |
| BREMBO | F56099 |
| BUDWEG CALIPER | 343043 |
| Brake ENGINEERING | CA2058R |
| CARDONE | 384137 |
| CEF | 6504027 |
| DELCO REMY | DC83043 |
| DELPHI | LC7524 |
| DRI | 3280200 |
| ELSTOCK | 83-0820 |
| FRIESEN | QBS3246 |
| FTE | RX459834A0 |
| HELLA | 8AC355386-481 |
| OPEL | 4501215, 7701205764, 9161515 |
| RE-EX | 506-02477 |
| RENAULT | 7701205764 |
| TMI | BR002477 |
| TRW | BHU258E |
| UBD | 54653 |
| VAUXHALL | 9161515 |
| VOLVO | 8111959 |
| sbs | 13012136104 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| MOVANO A Van (X70) 1.9 DTI (FD) | 2000-09 – 2001-10 | 59 | 80 | 1870 | |
| MOVANO A Van (X70) 1.9 DTI (FD) | 2001-10 – … | 60 | 82 | 1870 | |
| MOVANO A Van (X70) 2.2 DTI (FD) | 2000-09 – … | 66 | 90 | 2188 | |
| MOVANO A Van (X70) 2.5 CDTI (FD) | 2003-10 – … | 74 | 101 | 2464 | |
| MOVANO A Van (X70) 2.5 D (FD) | 1999-01 – 2000-09 | 59 | 80 | 2499 | |
| MOVANO A Van (X70) 2.5 DTI (FD) | 2001-10 – … | 84 | 115 | 2463 | |
| MOVANO A Van (X70) 2.8 DTI (FD) | 1999-01 – 2001-10 | 84 | 114 | 2799 | |
| MOVANO A Bus (X70) 1.9 DTI (JD) | 2000-09 – 2001-10 | 59 | 80 | 1870 | |
| MOVANO A Bus (X70) 1.9 DTI (JD) | 2001-10 – … | 60 | 82 | 1870 | |
| MOVANO A Bus (X70) 2.2 DTI (JD) | 2000-09 – … | 66 | 90 | 2188 | |
| MOVANO A Bus (X70) 2.5 CDTI (JD) | 2007-09 – … | 74 | 101 | 2464 | |
| MOVANO A Bus (X70) 2.5 D (JD) | 1998-07 – 2000-09 | 59 | 80 | 2499 | |
| MOVANO A Bus (X70) 2.5 DTI (JD) | 2001-10 – … | 84 | 115 | 2463 | |
| MOVANO A Bus (X70) 2.8 DTI (JD) | 1998-07 – 2001-10 | 84 | 114 | 2799 | |
| MOVANO A Platform/Chassis (X70) 2.5 CDTI (ED, HD, UD0, UD4) | 2006-08 – … | 74 | 101 | 2464 | |
| MASTER II Van (FD) 1.9 dCi 80 (FD0P) | 2001-11 – 2006-10 | 60 | 82 | 1870 | |
| MASTER II Van (FD) 1.9 dTI (FD0L) | 1997-12 – 2002-03 | 59 | 80 | 1870 | |
| MASTER II Van (FD) 2.2 dCI 90 (FD0G, FD0N, FD2G, FD2N, FD3G, FD3N) | 1997-12 – 2006-10 | 66 | 90 | 2188 | |
| MASTER II Van (FD) 2.5 D (FD0A, FD0E, FD2E, FD3E) | 1998-07 – 2001-01 | 59 | 80 | 2499 | |
| MASTER II Van (FD) 2.5 dCi 100 (FD0U, FD0V, FD3U, FD3V, FD8U, FD8V) | 2003-10 – 2010-03 | 73 | 99 | 2463 | |
| MASTER II Van (FD) 2.5 dCi 120 (FD0M, FD0U, FD0W, FD2M, FD2W, FD3M, FD3U,… | 2001-10 – 2007-09 | 84 | 115 | 2463 | |
| MASTER II Van (FD) 2.8 dTI (FD0C, FD0F, FD2B, FD2F, FD3C, FD3F) | 1998-07 – 2001-10 | 84 | 114 | 2799 | |
| MASTER II Bus (JD) 1.9 dCi 80 (JD0P, JD1P) | 2001-11 – 2006-10 | 60 | 82 | 1870 | |
| MASTER II Bus (JD) 1.9 dTI (JD0L, JD1L) | 1997-12 – 2002-03 | 59 | 80 | 1870 | |
| MASTER II Bus (JD) 2.2 dCI 90 (JD0G, JD0N, JD1N) | 1997-12 – 2006-09 | 66 | 90 | 2188 | |
| MASTER II Bus (JD) 2.5 D (JD1A, JD0E, JD0A, JD1E) | 1998-07 – 2001-01 | 59 | 80 | 2499 | |
| MASTER II Bus (JD) 2.5 dCi 100 (JDCV, JD1W) | 2003-10 – 2010-01 | 73 | 99 | 2463 | |
| MASTER II Bus (JD) 2.8 dTI (JD0B, JD0F, JD1B, JD1F) | 1998-07 – 2001-10 | 84 | 114 | 2799 | |
| MASTER II Bus (JD) 3.0 dCi 140 (JD0T, JD1T) | 2003-10 – 2006-09 | 100 | 136 | 2953 | |
| MASTER II Platform/Chassis (ED/HD/UD) 2.2 dCI 90 (ED0G, ED0N, HD0G, HD0N, HD1G, HD1N, UD0G,… | 1997-12 – 2006-09 | 66 | 90 | 2188 | |
| MASTER II Platform/Chassis (ED/HD/UD) 2.5 D | 1998-07 – 2001-01 | 59 | 80 | 2499 | |
| MASTER II Platform/Chassis (ED/HD/UD) 2.5 dCi 100 (ED4V, ED8V, ED0U, ED0V, ED8U, HD0U, HD0V,… | 2002-10 – 2010-05 | 73 | 99 | 2463 | |
| MASTER II Platform/Chassis (ED/HD/UD) 2.8 dTI | 1998-07 – 2001-10 | 84 | 114 | 2799 |
