Description
Specifications
| External Thread Size | M14 x 1,5 |
| Piston Rod Diameter | 20 mm |
| Shock Absorber Type | Oil Pressure |
| min. length | 311 mm |
| Shock Absorber Design | Telescopic Shock Absorber |
| max. length | 508 mm |
| Shock Absorber Mounting Type | Top pin; Bottom Pin |
| Fitting Position | Rear Axle |
| Pipe Diameter | 73 mm; 64 mm |
| Weight | 4.056 kg |
| Country of Origin | Germany |
| Customs Code | 870880 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| EVOBUS | 628 326 08 00, 628 326 11 00, 628 326 12 00, 628 326 16 00, 628 326 18 00, 628 326 23 00, 628 326 24 00, 628 326 25 00, 628 326 26 00, 628 326 27 00, A628 326 08 00, A628 326 11 00, A628 326 12 00, A628 326 16 00, A628 326 18 00, A628 326 23 00, A628 326 24 00, A628 326 25 00, A628 326 26 00, A628 326 27 00 |
| MERCEDES-BENZ | 628 326 08 00, 628 326 11 00, 628 326 12 00, 628 326 16 00, 628 326 18 00, 628 326 23 00, 628 326 24 00, 628 326 25 00, 628 326 26 00, 628 326 27 00, A628 326 08 00, A628 326 11 00, A628 326 12 00, A628 326 16 00, A628 326 18 00, A628 326 23 00, A628 326 24 00, A628 326 25 00, A628 326 26 00, A628 326 27 00 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| AUGER | 20905 |
| BOGE | 40-C53-0 |
| DT Spare Parts | 4.65618 |
| EVOBUS | 628 326 08 00, 628 326 11 00, 628 326 12 00, 628 326 16 00, 628 326 18 00, 628 326 23 00, 628 326 24 00, 628 326 25 00, 628 326 26 00, 628 326 27 00, A628 326 08 00, A628 326 11 00, A628 326 12 00, A628 326 16 00, A628 326 18 00, A628 326 23 00, A628 326 24 00, A628 326 25 00, A628 326 26 00, A628 326 27 00 |
| KONI | 8805-1024 |
| MERCEDES-BENZ | 628 326 08 00, 628 326 11 00, 628 326 12 00, 628 326 16 00, 628 326 18 00, 628 326 23 00, 628 326 24 00, 628 326 25 00, 628 326 26 00, 628 326 27 00, A628 326 08 00, A628 326 11 00, A628 326 12 00, A628 326 16 00, A628 326 18 00, A628 326 23 00, A628 326 24 00, A628 326 25 00, A628 326 26 00, A628 326 27 00 |
| MONROE | B1283 |
| Magnum Technology | M0064 |
| SACHS | 290 991 |
| SAMPA | 209.439 |
| ST-TEMPLIN | 04.170.7950.286 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| CITARO (O 530) Citaro, Citaro MUE | 1998-01 – … | 210 | 286 | 6374 | |
| CITARO (O 530) Citaro C | 1999-05 – … | 210 | 7201 |
