Description
Specifications
| External Thread Size | M16 x 1,5 |
| Mounting points diameter | 20 mm |
| Piston Rod Diameter | 16 mm |
| Shock Absorber Type | Oil Pressure |
| min. length | 465 mm |
| Shock Absorber Design | Telescopic Shock Absorber |
| max. length | 778 mm |
| Shock Absorber Mounting Type | Top pin; Bottom eye |
| Fitting Position | Rear Axle |
| Pipe Diameter | 76 mm; 63 mm |
| Weight | 6.63 kg |
| Country of Origin | Germany |
| Customs Code | 870880 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| MERCEDES-BENZ | 002 326 46 00, 002 326 47 00, 003 326 45 00, 003 326 92 00, 006 326 64 00, 385 326 01 00, A002 326 46 00, A002 326 47 00, A003 326 45 00, A003 326 92 00, A006 326 64 00, A385 326 01 00 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| AUGER | 20914 |
| BOGE | 40-774-0 |
| DT Spare Parts | 4.65991 |
| GABRIEL | 4065 |
| KONI | 90-5141 |
| MERCEDES-BENZ | 002 326 46 00, 002 326 47 00, 003 326 45 00, 003 326 92 00, 006 326 64 00, 385 326 01 00, A002 326 46 00, A002 326 47 00, A003 326 45 00, A003 326 92 00, A006 326 64 00, A385 326 01 00 |
| MONROE | T5054 |
| PE Automotive | 013.459-00A |
| SACHS | 106 946 |
| ST-TEMPLIN | 04.170.1000.063, 04.170.7950.058 |
| TRW | JHZ5057 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| NG 1013 | 1976-02 – 1984-12 | 96 | 130 | 5675 | |
| NG 1017 | 1975-11 – 1991-02 | 124 | 168 | 5675 | |
| NG 1017 K | 1976-02 – 1984-12 | 124 | 168 | 5675 | |
| NG 1213 | 1975-09 – 1986-05 | 96 | 130 | 5675 | |
| NG 1217,1217 L | 1973-08 – 1996-09 | 124 | 168 | 5675 | |
| NG 1217 K | 1975-09 – 1984-12 | 124 | 168 | 5675 | |
| NG 1219 | 1975-09 – 1984-09 | 141 | 192 | 9570 | |
| NG 1219 K | 1975-09 – 1984-09 | 141 | 192 | 9570 | |
| NG 1413 | 1975-09 – 1984-12 | 96 | 130 | 5675 | |
| NG 1414 K | 1984-04 – 1991-03 | 100 | 136 | 5960 | |
| NG 1417 | 1975-05 – 1984-12 | 124 | 168 | 5675 | |
| NG 1417 K | 1975-05 – 1984-12 | 124 | 168 | 5675 | |
| NG 1419,1419 L | 1973-08 – 1996-09 | 141 | 192 | 9570 | |
| NG 1419 K | 1975-05 – 1982-12 | 141 | 192 | 9570 | |
| NG 1424,1424 L | 1973-08 – 1996-09 | 176 | 240 | 12763 | |
| NG 1424 K | 1975-07 – 1987-01 | 176 | 240 | 12763 | |
| NG 1613,1613 L | 1973-08 – 1996-09 | 96 | 130 | 5675 | |
| NG 1613 K | 1975-01 – 1984-12 | 96 | 130 | 5675 | |
| NG 1614 K | 1984-04 – 1991-03 | 100 | 136 | 5960 | |
| NG 1617,1617 L | 1973-08 – 1996-09 | 124 | 168 | 5675 | |
| NG 1617 K | 1975-01 – 1985-07 | 124 | 168 | 5675 | |
| NG 1617 CK | 1984-04 – 1991-03 | 125 | 170 | 5960 | |
| NG 1619,1619 L | 1973-08 – 1996-09 | 141 | 192 | 9570 | |
| NG 1619 K | 1974-11 – 1982-12 | 141 | 192 | 9570 | |
| NG 1622 K | 1982-05 – 1989-10 | 159 | 216 | 10964 | |
| NG 1624,1624 L | 1973-08 – 1996-09 | 176 | 240 | 12763 | |
| NG 1624 K | 1975-07 – 1982-08 | 176 | 240 | 12763 | |
| NG 1625 K | 1980-05 – 1989-11 | 184 | 250 | 14618 | |
| NG 2219 C,2219 CL | 1973-08 – 1996-09 | 141 | 5675 | ||
| NG 2220,2220 L | 1973-08 – 1996-09 | 150 | 5958 | ||
| NG 2222,2222 L | 1973-08 – 1996-09 | 159 | 10964 | ||
| NG 1619 K | 1973-08 – 1996-12 | 144 | 10456 | ||
| NG 1619 | 1973-08 – 1996-12 | 144 | 10456 | ||
| NG 1219 | 1973-08 – 1996-12 | 144 | 10456 | ||
| NG 1219 K | 1973-08 – 1996-12 | 144 | 10456 | ||
| NG 1419 K | 1973-08 – 1996-12 | 144 | 10456 | ||
| NG 1620 K | 1973-08 – 1996-12 | 150 | 5958 | ||
| NG 1017 | 1973-08 – 1996-12 | 125 | 5958 | ||
| NG 1622 K | 1973-08 – 1996-12 | 165 | 11309 | ||
| NG 2225 | 1973-08 – 1996-12 | 184 | 14618 | ||
| NG 2219 | 1973-08 – 1996-12 | 141 | 5675 | ||
| NG 2219 | 1973-08 – 1996-12 | 141 | 9570 |
