Description
Specifications
| Hub Inner Diameter | 86 mm |
| Hub mounting bore diameter | 14.7 mm |
| Hub Outer Diameter | 155 mm |
| Pitch Circle Diameter, hub | 125 mm |
| Number of mounting bores on the hub | 12 |
| Pitch Circle Diameter, clutch pressure plate | 410 mm |
| Inner Diameter Tread | 193 mm |
| Clutch Pressure Plate Outer Diameter | 435 mm |
| Number of mounting bores on the clutch pressure plate | 12 |
| Number of Teeth | 154 |
| Supplementary Article/Supplementary Info | with starter motor sprocket |
| Observe service information | |
| Weight | 40.934 kg |
| Country of Origin | Germany |
| Customs Code | 870893 |
OE (Original Equipment) Numbers
| Brand | Reference Numbers |
|---|---|
| MERCEDES-BENZ | 346 030 00 05, 346 030 00 05, 346 030 16 05, 346 030 16 05, 355 030 09 05, 355 030 13 05, A346 030 00 05, A346 030 00 05, A346 030 16 05, A346 030 16 05, A355 030 09 05, A355 030 13 05 |
Cross-Reference Numbers
| Brand | Reference Numbers |
|---|---|
| AUGER | 58383 |
| BF | 20 0903 35500 |
| CLUTCHNUS | MFW101 |
| DT Spare Parts | 4.61111 |
| ETG Automotive | 02.01.03.200376 |
| GERMO | 51802 |
| KAWE | V6022N |
| KTK GERMANY | 11010 |
| MEC-DIESEL | 181085 |
| MERCEDES-BENZ | 346 030 00 05, 346 030 16 05, 355 030 09 05, 355 030 13 05, A346 030 00 05, A346 030 16 05, A355 030 09 05, A355 030 13 05 |
| OREX | 103032 |
| SACHS | 3421 601 001 |
| SAMPA | 209.086 |
| SEM LASTIK | 13062 |
| ST-TEMPLIN | 08.150.1001.170 |
| STELLOX | 81-28342-SX |
| SWAG | 10 01 0001 |
| TRUCKTEC AUTOMOTIVE | 01.11.032 |
| WILMINK GROUP | WG1815275 |
Compatible Vehicles
| Make | Model | Production Period | KW | HP | CCM |
|---|---|---|---|---|---|
| T2/L L 2624 | 1959-01 – 1995-01 | 175 – 184 | 238 – 250 | 11581 | |
| T2/L LK 2624 | 1959-01 – 1995-01 | 175 – 184 | 238 – 250 | 11581 | |
| T2/L LS 2624 | 1959-01 – 1995-01 | 175 – 184 | 238 – 250 | 11581 | |
| T2/L LA 2624 | 1959-01 – 1995-01 | 175 – 184 | 238 – 250 | 11581 | |
| T2/L LAK 2624 | 1959-01 – 1995-01 | 175 – 184 | 238 – 250 | 11581 | |
| T2/L LAS 2624 | 1959-01 – 1995-01 | 175 – 184 | 238 – 250 | 11581 | |
| T2/L LAB 2624 | 1959-01 – 1995-01 | 175 – 177 | 238 – 241 | 11581 | |
| T2/L LB 2624 | 1959-01 – 1995-01 | 175 – 177 | 238 – 241 | 11581 |
